Midmark 623 Barrier-Free Power Examination Table

Midmark 623 Barrier-Free Exam Table

Offering the Midmark 623 Barrier-Free Exam Table for sale.
Patients you see are all different. But the one thing they may have in common is difficulty accessing the exam table. Easy access to the exam table can decrease strain on patients and staff, and ensure that you can position all patients effectively for a more thorough and accurate exam. Break down the barriers in the exam room with a Midmark 623 Barrier-Free Exam Table and provide all of your patients with equal care regardless of physical condition.

Midmark 623 Barrier-Free Exam Table Features

• Power height and back
• 400-pound patient weight capacity
• 18-inch to 37-inch seat height adjustment
• Hand or foot control
• Receptacle and rear storage pod (standard)

The Midmark 623 Barrier-Free Exam Table helps your practice run smoothly. The power control enables you to get your patient onto and off the table effortlessly, and allows precise positioning in just seconds. More importantly, the Midmark 623 helps you build a better reputation for your practice.

Midmark 623 Barrier-Free Exam Table Specifications

• Dimensions (top): 28-1/3″ W x 59-1/2″ L
• Length with footrest extended: 77-1/2″
• Height: Minimum 18″, Maximum 37″
• Patient Load Rating: 400 lbs
• Stirrups: Standard
• Pelvic Tilt 5°
• Drawer Temperature: 98 °F
• Heated Upholstery Top: Prepared /OPTIONAL
• Temperature Range: 98 °F to 105 °F
• Duplex, hospital grade, electrical receptacle on left side /OPTIONAL
• Rear storage pod: (includes removable divider) 17.8″ x 7.0″ x 9.8″ H
• 115 VAC, 50/60 Hz, 12.5 Amps (basic unit)
• 115 VAC, 50/60 Hz, 13.5 Amps (with heaters)
• Paper Roll (maximum size): 21″ L x 3-1/2″ diameter
  • Export models 19-2/3″ L x 4-3/4″ diameter
• Net Weight
  • With Upholstery: 325 lbs
  • With packaging and skid (no upholstery): 375 lbs
  • Weight of Upholstery with packaging: 40 lbs
• Power Cord(s) [115V models have two cords]: 8 feet long
• Foot Control Voltage: 14 VAC, (Safety Extra Low Voltage)
• Duplex Receptacle maximum load: 115 VAC | 5 A
• Duty Cycle
  • Actuator motor run time: Intermittent Operation
    • (Domestic: 30 seconds ON / 5 minutes OFF)
    • (Export: 25 seconds ON / 7 minutes OFF)
  • Receptacle / Drawer Heater: Continuous Operation
• Classifications: Class I, Type B Applied Part, Ordinary Equipment, Intermittent Operation
• Certifications: UL 60601-1 and CAN/CSA-C22.2 No.601.1-M90
• Protection against ingress of fluids: IPX0 [Foot Control only: IPX1]
• Table Speeds (by function)
  • Base: 14 – 26 seconds
  • Back:15 – 20 seconds

The Midmark 623 Barrier-Free Exam Table features new technology and a new look. It complies with ADA guidelines and serves healthcare professionals domestically and globally. Empower your patient with accessibility, dignity, safety and comfort.
