Schiller Cardiovit AT-10 Plus ECG

Schiller Cardiovit AT-10 Plus ECG EKG

The Schiller Cardiovit AT-10 Plus ECG combines the basics of electrocardiography with the benefits of the IT world. A Schiller Cardiovit AT-10 Plus ECG combines resting ECG, exercise ECG, pacemaker measurement, HRV analysis, signal-averaged ECG analysis, thrombolysis software and spirometry in a single system – like its legendary predecessor, the Cardiovit AT-10. It does not only provide all functions of a high-quality 12-channel electrocardiograph but also meets the requirements of an integrated diagnostic workstation. Its brilliant communication concept makes the AT-10 plus an extremely flexible tool.

• New: Detection of coronary artery obstruction (C.A.)
• Heart Rate Variability (HRV)
• Signal-averaged ECG (SAECG ), former Late Potential
• Rhythm ECG Recording (in full disclosure)
• Exercise ECG
• Pacemaker measurement
• Thrombolysis recommendation software
• Vectorcardiography (with SEMA-200 data management system)
• Serial ECG comparison (with SEMA-200 data management system)
• Complete pulmonary function tests for slow and forced spirometry

Schiller Cardiovit AT-10 plus ECG performance Features

• Compact laptop design
• Single button operation for printing, storage, and transmission
• 12/16 channel resting and exercise ECG
• High-resolution 10.4″ TFT color display
• Built-in thermal printer with A4 printing paper
• Worklist (for auto-download of patient demographic data from the ECG Management Systems)
• Ethernet networking
• WLAN (optional)
• Risk stratification tools such as Thrombolysis, HRV and Signal Averaged ECG (SAECG)
• Barcode scanner, to reduce misspellings
• Internal memory for up to 350 ECG recordings
• Rechargeable battery for mobile use

ERGOMETRY

The most commonly used test protocols are already programmed in your CARDIOVIT AT-10 plus. Five (treadmill) or four (bicycle) user definable protocols allow you to store or modify programs exactly as you wish. The exercise testing program controls a bicycle ergometer or treadmill. Non-invasive blood pressure measurement is taken automatically at the beginning of every load stage or at freely definable intervals, and indicated on the monitor and on printouts. The blood pressure can be measured using the BP-200 plus or the BP recorder integrated with the ERG 911 (optional). Continuously updated ECG information, including the heart rate, stage number and duration, exercise period, load and METs are displayed on-screen and documented on the printout. A comprehensive final report is printed out at the end of each exercise test. The advanced evaluation program EXEC provides you with continuous 12-lead ST information during the test and a comprehensive final report.
